Buyer’s Guide: Robinair® Recover, Recycle & Recharge Models
Premier R-134A Machine
Shop @ ToolTopia.com: #ROB34788NI
Premier R-134A Machine for Hybrid and Non-Hybrid Vehicles
Shop @ ToolTopia.com: #ROB34788NIH
Classic Economy Cooltech R-134A Machine
Shop @ ToolTopia.com: #ROB34288
Classic Premium Cooltech R-134A Machine
Shop @ ToolTopia.com: #ROB34988
1234YF Machine
Shop @ ToolTopia.com: #ROBAC12346
R-134A • Premier Models
Unmatched Performance of 98.5% Recovery
Recover, recycle, evacuate, leak-test and recharge R-134a with improved 98.5% efficiency – unmatched by any competitor.
New Design with Improved Screen Display
Features a larger graphical color display, automatic features including leak testing, automatic refrigerant refill and oil drain/inject – putting A/C lubricant back into the system.
Future Expandability
An optional refrigerant charge and oil capacities database is available for North American market vehicles. Coming Soon: the ability to add a printer, USB data sharing, refrigerant identifier and wireless module for Wi-Fi or Bluetooth® communication. (Expected by end of 2015)
Premier R-134A
Refrigerant Recovery, Recycling & Recharging Machine
Shop @ ToolTopia.com: #ROB34788NI
- Fully-Automatic Function: Program to recover, vacuum, leak test and charge without operating panel valves.
- Automatic Oil Drain: A display reminds you to empty the graduated container to show the amount of oil to replace.
- Oil Inject: Automatically inject oil back into the vehicle’s A/C systems.
- Refrigerant & Oil Database: A/C system capacities for North American market vehicles(Optional – not included with the machine)
- Save & print before and after service data: Allows the user to store before and after service information by vehicle and print this information to provide to a customer. (Printer Optional – not included with the machine)
- Visual & Audible Alarm: Notifies the user when service is complete, or if a problem has occurred.
- Vacuum Leak Test: Monitors level after evacuation, informs of possible leak.
- Automatic Air Purge: Eliminates system-damaging air without monitoring gauges or opening valves.
- Automatic Refrigerant Refill: Maintains a user-selectable amount of refrigerant in an internal vessel and signals when it’s time to change supply tank, no monitoring required.
- Vacuum Feature: Defaults to 15 mins, programmable up to 99 mins. “Remaining time” is displayed.
- Display: Multilingual
- Refrigerant Charging: Select a charge mode from high or low side, or use both sides.
- Refrigerant Management System: Displays refrigerant use and monitors remaining filter life. Prompts appear when 1/3 of filter life remains.
- Optional On-board Printer
- Optional Refrigerant Identifier
- SPECIFICATIONS:
- Dimensions: 36in x 24in x 48.5in
- Weight: 232.00 lb
- Operating Range: 32° – 120°F (0°-50°C)
- Recovery Performance: >95% at 70 to 75° F (21 to 24°C) <30 minutes
- Voltage: 125 VAC 60 Hz
- Charge Performance: +/- 0.5 oz at 70° to 75° F (+/- 15g at 21° to 24° C)
- Display: 5 cm x 9 cm graphical display
- Filter-Drier Capacity: 150 lb (75kg), spin-on type
- Hoses: 9 ft (2.75 m)
- Weight: Approximately 230 lbs. (103 kg)
- Compressor: 3/8 hp, pressure protected, oiled, hermetically sealed
- Vacuum Pump: 1.5 cfm Dual Stage, 29.9 InHg
- Languages: English, French, Spanish, Portuguese
- Internal Cylinder: 30 lb. DOT
- Certifications: SAE J2788
Premier R-134A • Hybrid and Non-Hybrid Vehicles
Refrigerant Recovery, Recycling & Recharging Machine
Shop @ ToolTopia.com: #ROB34788NIH
- Fully-Automatic Function: Program to recover, vacuum, leak test and charge without operating panel valves.
- Automatic Oil Drain: A display reminds you to empty the graduated container to show the amount of oil to replace.
- Refrigerant & Oil Database: A/C system capacities for North American market vehicles(Optional – not included with the machine)
- A/C System Flush: Flushes a vehicle’s A/C system with refrigerant, eliminating any residual oil or other liquid.(Flushing adapters not included)
- Save & print before and after service data: Allows the user to store before and after service information by vehicle and print this information to provide to a customer. (Printer Optional – not included with the machine)
- Visual & Audible Alarm: Notifies the user when service is complete, or if a problem has occurred.
- Vacuum Leak Test: Monitors level after evacuation, informs of possible leak.
- Automatic Air Purge: Eliminates system-damaging air without monitoring gauges or opening valves.
- Automatic Refrigerant Refill: Maintains a user-selectable amount of refrigerant in an internal vessel and signals when it’s time to change supply tank, no monitoring required.
- Vacuum Feature: Defaults to 15 mins, programmable up to 99 mins. “Remaining time” is displayed.
- Display: Multilingual
- Refrigerant Charging: Select a charge mode from high or low side, or use both sides.
- Refrigerant Management System: Displays refrigerant use and monitors remaining filter life. Prompts appear when 1/3 of filter life remains.
- Electric Vehicle: Capable of servicing high voltage electric compressor A/C systems.
- Optional On-board Printer
- Optional Refrigerant Identifier
- SPECIFICATIONS:
- Dimensions: 36in x 24in x 48.5in
- Weight: 232.00 lb
- Operating Range: 32° – 120°F (0°-50°C)
- Recovery Performance: >95% at 70 to 75° F (21 to 24°C) <30 minutes
- Voltage: 125 VAC 60 Hz
- Charge Performance: +/- 0.5 oz at 70° to 75° F (+/- 15g at 21° to 24° C)
- Display: 5 cm x 9 cm graphical display
- Filter-Drier Capacity: 150 lb (75kg), spin-on type
- Hoses: 9 ft (2.75 m)
- Weight: Approximately 230 lbs. (103 kg)
- Compressor: 3/8 hp, pressure protected, oiled, hermetically sealed
- Vacuum Pump: 1.5 cfm Dual Stage, 29.9 InHg
- Languages: English, French, Spanish, Portuguese
- Internal Cylinder: 30 lb. DOT
- Certifications: SAE J2788
R-134A • Classic Models
Simple Operation with 95% Recovery
Whether it’s the fully-automatic 34988 or the semi-automatic 34288, these machines will test, recover, and recharge R-134A automotive AC systems quickly and accurately.
Economy Cooltech R-134A
Recover, Recycle, Evacuate & Recharge Machine
Shop @ ToolTopia.com: #ROB34288
- Automatic Oil Drain: A display reminds you to empty the graduated container to show the amount of oil to replace.
- Automatic Air Purge: Eliminates damaging air without monitoring gauges or opening valves.
- Automatic Refrigerant Refill: Maintains a user-selectable amount of refrigerant in an internal vessel and signals when it’s time to change supply tank, no monitoring required.
- Multilingual Display
- Refrigerant Management System: Displays refrigerant use and monitors remaining filter life. Prompts appear when 1/3 of filter life remains.
- Refrigerant Charging: High or Low
- SPECIFICATIONS:
- Dimensions: 49in x 34in x 23in
- Weight: 225.00 lb
- Operating Range: 50° – 120°F (11°-49°C)
- Recovery Performance: 95%
- Voltage: 115 VAC 60 Hz
- Utilization Voltage Range: 104-127
- Charge Performance: +/- 0.5 oz
- Filter-Drier Capacity: 43 cu. in., spin-on type
- Pump Free-Air Displacement: 1.5 cfm (42 l/m)
- Certifications: SAE J2788
Premium Cooltech R-134A
Recover, Recycle, Evacuate & Recharge Machine
Shop @ ToolTopia.com: #ROB34988
- Automatic Dye Inject: Gives the user the ability to use the machine to inject UV dye into a vehicle’s A/C system.
- Automatic Oil Measure & Inject: The machine will automatically determine how much lubrication oil needs to be injected back into the A/C system based on how much oil was taken out during recovery.
- Automatic Oil Drain: A display reminds you to empty the graduated container to show the amount of oil to replace.
- Oil Inject: Less than 1% cross-contamination.
- Optional Refrigerant & Oil Database: Includes A/C Charge and Oil Capacities for North American market vehicles.
- A/C System Flush: Flushes a vehicle’s A/C system with refrigerant eliminating an residual oil or other liquid. (Flushing adapters not included)
- Save & Print Before & After Service Data: Allows the user to store before and after service information by vehicle and print this information to provide to a customer.
- Standard Onboard Printer: Already built in, the service data is easily printed out.
- Indicator Light & Notification Alarm: Notifies the user when service is complete, or if a problem has occurred.
- Vacuum Leak Test: Monitors level after evacuation, informs of possible leak.
- Automatic Air Purge: Eliminates damaging air without monitoring gauges or opening valves.
- Automatic Refrigerant Refill: Maintains a user-selectable amount of refrigerant in an internal vessel and signals when it’s time to change supply tank, no monitoring required.
- Vacuum Feature: Defaults to 15 mins, programmable up to 99 mins. “Remaining time” is displayed.
- Multilingual Display
- Refrigerant Management System: Displays refrigerant use and monitors remaining filter life. Prompts appear when 1/3 of filter life remains.
- SPECIFICATIONS:
- Dimensions: 49in x 34in x 23in
- Weight: 232.00 lb
- Operating Range: 50° – 120°F (11°-49°C)
- Recovery Performance: 95%
- Voltage: 115 VAC 60 Hz
- Utilization Voltage Range: 104-127
- Charge Performance: +/- 0.5 oz
- Filter-Drier Capacity: 43 cu. in., spin-on type
- Pump Free-Air Displacement: 1.5 cfm (42 l/m)
- Certifications: SAE J2788
R-134A • Comparison Chart
| FEATURES | Premier R-134A Machine (ROB34788NI) | Premier R-134A Machine for Hybrid & Non-Hybrid Vehicles (ROB34788NIH) | Classic Economy Cooltech Machine (ROB34288) | Classic Premium Cooltech Machine (ROB34988) |
|---|---|---|---|---|
| Fully-Automatic Function: Program to recover, vacuum, leak test and charge without operating panel valves | X | X | X | |
| Automatic Oil Drain: A display reminds you to empty the graduated container to show the amount of oil to replace. | X | X | X | X |
| Automatic Dye Inject: Gives the user the ability to use the machine to inject UV dye into a vehicle’s A/C system. | X | |||
| Oil Inject: Automatically inject oil back into the vehicle’s A/C systems. | X | X | ||
| Automatic Oil Measure & Inject: The machine will automatically determine how much lubrication oil needs to be injected back into the A/C system based on how much oil was taken out during recovery. | X | |||
| Refrigerant & Oil Database: A/C system capacities for North American market vehicles (Optional – not included with the machine) | OPTIONAL | OPTIONAL | OPTIONAL | |
| A/C System Flush: Flushes a vehicle’s A/C system with refrigerant, eliminating any residual oil or other liquid. (Flushing adapters not included) | X | OPTIONAL | ||
| Save & print before and after service data: Allows the user to store before and after service information by vehicle and print this information to provide to a customer. | X | X | X | |
| Printer. | OPTIONAL | OPTIONAL | X | |
| Visual & Audible Alarm: Notifies the user when service is complete, or if a problem has occurred | X | X | X | |
| Vacuum Leak Test: Monitors level after evacuation, informs of possible leak. | X | X | X | |
| Automatic Air Purge: Eliminates system-damaging air without monitoring gauges or opening valves. | X | X | X | X |
| Automatic Refrigerant Refill: Maintains a user-selectable amount of refrigerant in an internal vessel and signals when it’s time to change supply tank, no monitoring required. | X | X | X | |
| Vacuum Feature: Defaults to 15 mins, programmable up to 99 mins. “Remaining time” is displayed | X | X | X | |
| Display: Multilingual. | X | X | X | |
| Refrigerant Charging: Select a charge mode from high or low side, or use both sides. | X | X | ||
| Refrigerant Charging: Select a charge mode from high or low side. | High/Low/Both | High/Low/Both | High/Low/Both | High or Low |
| Refrigerant Management System: Displays refrigerant use and monitors remaining filter life. Prompts appear when 1/3 of filter life remains. | X | X | X | |
| Refrigerant Identifier. | OPTIONAL | OPTIONAL | OPTIONAL | |
| Electric Vehicle: Capable of servicing high voltage electric compressor A/C systems. | X |
R-134A • Videos
R1234F • New Refrigerant Machine
Unique
The only product available today that fully meets SAE’s requirement for recovering, recycling and recharging vehicle A/C systems that use the new R1234YF refrigerant.
Dependable with 95% Recovery
A fully automatic ACS machine that comes with an integrated refrigerant identifier that samples the refrigerant in the vehicle’s A/C system prior to recovery, is a highly accurate and reliable machine, and can service both standard and hybrid vehicle A/C systems.
1234YF
Recover, Recycle & Recharge Machine
Shop @ ToolTopia.com: #ROBAC12346
- Can service both standard & hybrid vehicle A/C systems: The only product available today that fully meets SAE’s requirement for recovering, recycling and recharging vehicle A/C systems that use the new R1234YF refrigerant.
- Fully automatic operation: Program for service, walk away and return when complete.
- 95% recovery efficiency
- Programmable vacuum operation: Helps get to the necessary vacuum level in any condition quickly.
- System leak test: To identify gross leaks in a system.
- Charge accuracy: Within +/- ½ oz.
- Automatic oil drain: Shows how much oil was removed from the system during service.
- Automatic air purge: Removes the potential of air accumulating in the internal tank.
- Integrated refrigerant identifier: (meets SAE J2927)
- Liquid refrigerant flushing function: Can flush A/C systems or individual components using liquid refrigerant instead of harsh chemicals.
- Automatic internal tank refill: No stopping to fill the internal tank during service, or before service.
- 1/4 Color VGA display: Large easy to read graphical display
- On-board printer: Capable of printing vehicle service report slips to present to customers.
SPECIFICATIONS:
- Dimensions: 36in x 24in x 48.5in
- Operating voltage: 103-127V, 60Hz AC
- 100mm, EN837-1 pressure gauges
- Alpha-numeric keypad with service function keys
- 1.5 cfm dual stage vacuum pump
- 1/3 hp hermetic compressor
- 22 lb. ASME internal storage tank
- USB, SD, and RJ45 I/O ports
- 8 ft. SAE J2888 service hoses with 1234YF high and low side system couplers
- Meets all requirements of SAE J2843
R1234F • Videos
R-134A • Parts & Accessories
Premium High Vacuum Pump Oil – 1 Qt.
Shop @ ToolTopia.com: #ROB13203
Premium High Vacuum Pump Oil – (4) 1 Gallon
Shop @ ToolTopia.com: #ROB13204
Spin On Filter
Shop @ ToolTopia.com: #ROB34724
Maintenance Kit
Shop @ ToolTopia.com: #ROB13172
R-134A Oil Injector with 1/2″ Acme Quick Coupler
Shop @ ToolTopia.com: #ROB16256
R-134A Service Coupler – Low Side Blue
Shop @ ToolTopia.com: #ROB18190A
R-134A Service Coupler – High Side Red
Shop @ ToolTopia.com: #ROB18191A
High and Low Side R-134a Manual Coupler
Shop @ ToolTopia.com: #ROB18192
Printer – for Machines #34788NI or #34788NI-H
Shop @ ToolTopia.com: #ROB30038
Printer Paper (3-rolls)
Shop @ ToolTopia.com: #ROB34214
Manufacturer Info
Maintaining Your Recover, Recycle & Recharge Equipment
IPerforming regular maintenance check-ups will help keep your recover, recycle and recharge equipment in great condition and provide you with many years of dependable service.
Recovery, Recycle, and Recharge machines are built to provide years of reliable service. However, it is an electro-mechanical device and as such does require routine maintenance. Regular service intervals will help keep the machine running at peak performance levels. It is important to always read and follow manufacturers recommended service procedures.
Some of the items that require regular inspection are as follows:
Service Couplers
Typically dirt and debris in the service environment are the main causes of service couplers failure. Technicians must inspect the receiving end of the coupler to make sure it is clean and oil free. Also inspect the O-rings to make sure they are pliable and free of cuts or gouges. Finally, inspect the valve to ensure it is free of dirt and turns freely.
Hoses
It is important to inspect the hoses for cracked, abraded, or blistered areas. Cracks and abrasions indicate external wear whereas blisters generally indicate internal problems. If any of these wear indicators are present, it’s best to replace the hose. Also inspect the hose crimps and fittings on the end of the hoses as well as valve core depressors to make sure they are free of dirt and operate freely. Double check the gaskets for wear and pliability.
Refrigerant Scales
Refrigerant scales ensure that the correct amount of refrigerant is charged into the vehicles A/C system. Follow the manufacturer’s procedure for checking scale accuracy at least once per year or after service on the unit has been performed. If the unit is equipped with a DOT tank, examine it to make sure it is up to date.
Filters
While the inspection covers are still off, it is an ideal time to change the filters if necessary. Some recovery machines keep track of filter life based on the number of pounds of refrigerant filtered and prompt the user when it is time to change the filter. Some manufacturers recommend a filter change after servicing a certain number of vehicles. Either way, a properly maintained filter will keep the recovery machine running at peak performance. Always remember to inspect the gaskets and threads when changing filters.
Vacuum Pump Oil
If the recovery machine comes with a vacuum pump, make sure to change the pump oil when required. Vacuum pump oil is hydroscopic, which means it has an affinity for absorbing water, resulting in rust or scale build-up on internal components. Be careful not to overfill the vacuum pump. When this occurs, oil will discharge in the exhaust air and settle on other internal components attracting more dirt and debris. It may also cause the vacuum pump to smoke, prompting a service call.
General Maintenance
The machine itself has several internal components that should be inspected to ensure many years of dependable service. About every thirty days the unit should be inspected with an electronic refrigerant leak detector. While performing this task, a visual inspection of the electrical system can also be done. Check to make sure electrical connections are secure, the power cord is not damaged and that all the safety guards are installed properly.
Examine the periphery of the recovery machine; examine the wheels, casters, and cabinet for damage. Wheels or casters that do not move freely will at very least be an annoyance and may cause the unit to tip over. Lastly, protect the unit when not in use by using a dust cover. Dust covers not only keep dust from migrating to the internal parts of the machine, they also protect the machine from inadvertent bumps in a shop environment.
User Manuals
Instructions for safety, operation, maintenance of each product, and more, is available in the Unit’s User Manual. User Manuals are available for download at: Robinair.com
Product Technical Support and Customer Service
For technical support or troubleshooting of your unit, call:
Robinair® Customer Service: 800-628-6496 Fax: 800-283-8665
Robinair® Technical Service: 800-533-6127 Fax: 866-259-1241
Warranty and Repair Information
Robinair® provides factory warranty coverage for 1 year parts and labor with your equipment purchase. The warranty is only valid for the original purchaser of the unit. If your unit needs repair or replacement parts, contact the service center in your area.
Register your product online: https://register.servicesolutionsportal.com/
SOURCE: Robinair.com 2015; CONTENT POST: July 2015
